Three Electrode Cell Kit, Low Volume
Part Number
AF01CKT1006
This is a general purpose electrochemical cell designed for low volume applications. The overall cell volume is 10 mL and can be used down to approximately 5 mL. The low volume glass cell is designed to accommodate three LowProfile electrodes (working, counter, and reference). The cell kits consist of the cell, the Low Volume Cell Cap Kit, and two gas purge/sparge tubes.
Product Kit
This product is sold as a kit, meaning it consists of multiple independent products used together. View the individual kit products in the tab below.
Related Product Kits
This product is available in related kits. View related kits in the tab below.
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
This is a general purpose electrochemical cell designed for low volume applications. The overall cell volume is 10 mL and can be used down to approximately 5 mL. The low volume glass cell is designed to accommodate three LowProfile electrodes (working, counter, and reference). The cell kits consist of the cell, the Low Volume Cell Cap Kit, and two gas purge/sparge tubes.
The Low Volume Cell Series is designed for use with:
- OurLow Volume Cap Kit, which can be used in two configurations - open or closed to the atmosphere. The cap kit sealsaround all electrodes and probes in the cell.
- Pine Research's miniature aqueous and non-aqueous reference electrodes. These electrodes are a perfect fit for the 3.5 mm OD hole in the Low Volume cell cap.
- Platinum, gold, or glassy carbon LowProfile working electrodes. These electrodes fit the larger bore holes in the Low Volume Cap Kit.
- OurLowProfile platinum counter electrode has a 7 mm OD for the larger bore holes in the Low Volume Cap Kit.
Three Electrode Cell Kit, Low Volume is sold as a product kit. Product kits contain more than one product when purchased. Should you want more details on a specific part in the kit or wish to order an additional or replacement of a component, you can visit the product page for any item in the kit below.
Qty
Product Name
Part #
View Product
The Three Electrode Cell Kit, Low Volume is included in one or more kits. Below is a list of kits that contain this product.
Kit Name
Kit Part #
Kit Link
Three Electrode Cell Kit, Low Volume is sold as a product kit. The data below aggregates the specifications for each product contained within the kit.
Three Electrode Low Volume Cell Kit Component: Cell (Cell Only)
Electrochemical Cell
24/25 ports
Cell material
Cell volume (overall, max)
10 mL
Cell water jacket
Cell diameter
68 mm (hex base)
Cell height
25 mm
Cell application
Stationary
Cell series
Cell compatibility
Low volume cell series
Cell features
Low Volume Cell Series Cap Kit
Product Kits
Product kit
Cell kit type
Kit includes
Cell cap, Cell cap kit, O-rings, Plugs, Screws
- Dempsey, J.L.; Jackson, M.N.; Peroff, A.G. Meeting the Need: Formal Electrochemistry Training through Workshops. J. Chem. Educ. 2024, 101, 483-489.
- Esrafilzadeh, D.; Zavabeti, A.; Jalili, R.; Atkin, P.; Choi, J.; Carey, B.J.; Brkljača, R.; O’Mullane, A.P.; Dickey, M.D.; Officer, D.L.; MacFarlane, D.R.; Daeneke, T.; Kalantar-Zadeh, K. Room temperature CO2 reduction to solid carbon species on liquid metals featuring atomically thin ceria interfaces. Nat. Commun. 2019, 10, 865.
For this product, any applicable SDS will be listed here by category. You can view or download the SDS by clicking the appropriate button.
Material Group
Material Name
Actions
