Reference Electrode, Silver/Silver Chloride, Single Junction
Part Number
RREF0021
The standard-sized, single junction, silver/silver chloride (Ag/AgCl) reference electrode is filled with 4M KCl with AgCl solution. The refrerence electrode body is 9.5 mm OD, therefore ideally used with Standard volume electrochemical cells. The reference electrode is designed to be pass through a 14/20 ground glass joint and held in place by the included PTFE adapter, which can be adjusted to control the immersion depth of the reference electrode into the cell. Pine Research recommends proper storage and use of reference electrodes. A variety of useful tools for storage and care are shown below.
Related Product Bundles
This product is available in related bundles. View related bundles in the tab below.
Related Product Kits
This product is available in related kits. View related kits in the tab below.
Product Parts List
This product consists of separately available parts. View the parts list in the tab below.
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Compatibility Notice
Avoid using this reference electrode with the following: NH3 buffers, sulfides, perchlorates, non-aqueous/organic solvents, and alkaline solutions stronger than 0.1M OH–.
Thermal Stability Range: 10°C - 80°C
Electrode damage may occur at temperatures beyond recommended range. This range is provided for electrodes with PEEK shrouds.
Best Practice Suggestion: Employ a Laboratory Master Reference Electrode
A master reference electrode is a pristine, unused electrode kept exclusively to verify the accuracy of your active laboratory electrodes. By periodically measuring the potential difference between your everyday electrodes and the master in a shared electrolyte solution, you can quickly detect degradation and prevent experimental errors. To maintain its reliability as your ultimate baseline, the master electrode must never be used in actual experiments.
Compatible with Salt Bridge Kit
This reference electrode is compatible with the Salt Bridge Kit. A salt bridge enables use of a reference electrode in challenging conditions such as elevated temperature, solvent incompatibility, and chemical contamination risk.
Included in these Kits
This product is included in one or more kits. Below is a list of kits that contain this product.
Kit Name / Part #
Price
Standard Cell Kit, Utili-Shaft E
[SVC2-E1]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Standard Cell Kit, Utili-Shaft C
[SVC1-C1]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Three Electrode Cell Kit, Standard Volume, Gold (Au) Working Electrode
[WEB92-AU]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Corrosion Cell Kit, Coupon Cell
AFCELL4
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Three Electrode Cell Kit, Standard Volume, Glassy Carbon (GC) Working Electrode
[WEB92-GC]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Three Electrode Cell Kit, Standard Volume, Platinum (Pt) Working Electrode
[WEB92-PT]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Devanathan-Stachurski Hydrogen Permeation Cell Kit
[H2-PERM-CELL]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Available in these Bundles
This product is available as part of a product bundle (a combination of products that are compatible and often sold together for convenience).
Ungrouped
Bundle Name / Part #
Price
RRDE System Bundle: MSR evo, E8R4 Series RRDE
[MSR-RRDE-E6R1]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
RRDE System Bundle: MSR evo, E8R4 Series RRDE
[MSR-RRDE-E8R4]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveNow Wireless, MSR evo, E5 Series RDE
[WNW-MSR-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveNow Wireless, MSR evo, E5TQ Series RDE
[WNW-MSR-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveNow Wireless, WaveVortex 10, E5TQ Series RDE
[WNW-WV10-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveNow Wireless, WaveVortex 10, E5 Series RDE
[WNW-WV10-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveNow XV, MSR evo, E5 Series RDE
[WNXV-MSR-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveNow XV, MSR evo, E5TQ Series RDE
[WNXV-MSR-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveNow XV, WaveVortex 10, E5TQ Series RDE
[WNXV-WV10-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveNow XV, WaveVortex 10, E5 Series RDE
[WNXV-WV10-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
RRDE System Bundle: WaveVortex 10, E8R4 Series RRDE
[WV10-RRDE-E8R4]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
RRDE System Bundle: WaveVortex 10, E6R1 Series RRDE
[WV10-RRDE-E6R1]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
RDE System Bundle: WaveVortex 10, E5TQ Series RDE
[WV10-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
RDE System Bundle: WaveVortex 10, E5 Series RDE
[WV10-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RRDE System Bundle: WaveDriver 40, WaveVortex 10, E8R4 Series RRDE
[WD40-WV10-RRDE-E8R4]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
RDE System Bundle: MSR evo, E5TQ Series RDE
[MSR-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
RDE System Bundle: MSR evo, E5 Series RDE
[MSR-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RRDE System Bundle: WaveDriver 40, WaveVortex 10, E6R1 Series RRDE
[WD40-WV10-RRDE-E6R1]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RRDE System Bundle: WaveDriver 40, MSR evo, E8R4 Series RRDE
[WD40-MSR-RRDE-E8R4]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RRDE System Bundle: WaveDriver 40, MSR evo, E6R1 Series RRDE
[WD40-MSR-RRDE-E6R1]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 40, MSR evo, E5TQ Series RDE
[WD40-MSR-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 40, MSR evo, E5 Series RDE
[WD40-MSR-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 40, WaveVortex 10, E5TQ Series RDE
[WD40-WV10-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 40, WaveVortex 10, E5 Series RDE
[WD40-WV10-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 100, MSR evo, E5TQ Series RDE
[WD100-MSR-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 100, MSR evo, E5 Series RDE
[WD100-MSR-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 100, WaveVortex 10, E5TQ Series RDE
[WD100-WV10-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 100, WaveVortex 10, E5 Series RDE
[WD100-WV10-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RRDE System Bundle: WaveDriver 200, MSR evo, E8R4 Series RRDE
[WD200-MSR-RRDE-E8R4]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RRDE System Bundle: WaveDriver 200, MSR evo, E6R1 Series RRDE
[WD200-MSR-RRDE-E6R1]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 200, MSR evo, E5TQ Series RDE
[WD200-MSR-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 200, MSR evo, E5 Series RDE
[WD200-MSR-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RRDE System Bundle: WaveDriver 200, WaveVortex 10, E8R4 Series RRDE
[WD200-WV10-RRDE-E8R4]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RRDE System Bundle: WaveDriver 200, WaveVortex 10, E6R1 Series RRDE
[WD200-WV10-RRDE-E6R1]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 200, WaveVortex 10, E5TQ Series RDE
[WD200-WV10-RDE-E5TQ]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Complete RDE System Bundle: WaveDriver 200, WaveVortex 10, E5 Series RDE
[WD200-WV10-RDE-E5]
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
Reference Electrode, Silver/Silver Chloride, Single Junction
Reference Electrodes
Product Reference chemistry
Ag/AgCl
Product Standard potential
+199 mV vs NHE
Product Reference size type
Standard (9.5 mm OD)
Product Reference electrode body diameter
9.5 mm
Product Reference electrode length
19 cm
Product Reference frit material
Ceramic
Product External fill solution
4 M KCl with AgCl
Product Refillable
yes
Product Typical variance
±3 - 5 mV
Product Typical input impedance
< 10 kΩ
Product Reference electrode connection style
1.6 mm OD x 8.5 mm long brass pin
Product Reference electrode body material
borosilicate glass
4M Potassium Chloride with Silver Chloride Reference Electrode Filling SolutionView Product
Consumables
Product Product volume
250 mL
Standard Reference Electrode Adapter, 14/20 TaperView Product
General
Product Materials
Polytetrafluoroethylene (PTFE)
Reference Electrodes
Product Reference electrode body diameter
9.5 mm
Replacement Parts & Accessories
Customers may wish to order replacement or additional components of this product. Should you want more details or wish to order an additional part, refer to the list below.
Qty
Product Name / Part #
Price
1
4M Potassium Chloride with Silver Chloride Reference Electrode Filling Solution
RRSLN0001-250
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
1
Standard Reference Electrode Adapter, 14/20 Taper
ACEP1420A3
Login to View Prices
Customers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
- Ahmed, S.I.U.; Sankarasubramanian, S. Low pH Titanium Electrochemistry in the Presence of Sulfuric Acid and its Implications for Redox Flow Battery Applications. J. Electrochem. Soc. 2024, 171, 060538.
- Vu, K.N.; Law, C.S.; Lord, C.; Wang, J.; Lim, S.Y.; Horsley, J.; Nielsch, K.; Abell, A.D.; Santos, A. Harnessing the Intrinsic Ionic Rectification Properties of Blind-Hole Nanoporous Anodic Alumina for Osmotic Energy Generation. Adv. Funct. Mater. 2024, n/a, 2400697.
- Goyal, A.; Marcandalli, G.; Mints, V.A.; Koper, M.T.M. Competition between CO2 Reduction and Hydrogen Evolution on a Gold Electrode under Well-Defined Mass Transport Conditions. J. Am. Chem. Soc. 2020, 142, 4154-4161.
- San Roman, D.; Krishnamurthy, D.; Garg, R.; Hafiz, H.; Lamparski, M.; Nuhfer, N.T.; Meunier, V.; Viswanathan, V.; Cohen-Karni, T. Engineering Three-Dimensional (3D) Out-of-Plane Graphene Edge Sites for Highly Selective Two-Electron Oxygen Reduction Electrocatalysis. ACS Catal. 2020, 10, 1993-2008.
- Esayah, A.; Kelley, M.; Howell, A.; Shulder, S.J.; Mishra, B.; Olson, D.; Porter, J. Flow Accelerated Corrosion of Carbon Steel with Droplet Impingement Using a Modified Rotating Cylinder Electrode Experiment. Corrosion 2020, 76, 202-209.
Safety Data Sheets (SDS)
For this product, any applicable SDS will be listed here by category. You can view or download the SDS by clicking the appropriate button.
Reference Electrode Filling Solutions
4 M Potassium Chloride with Silver Chloride (KCl with AgCl)
Related Products and Accessories
-
Reference Electrode Storage Vessel, Standard
RRPG331Login to View PricesCustomers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region. -
Standard to LowProfile Reference Electrode Adapter
RRPG380Login to View PricesCustomers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region. -
Reference Electrode Storage Vessel Kit, OpenTop
AKREFHUT1Login to View PricesCustomers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region. -
Reference Electrode Storage Vessel Kit
AKREFHUT2Login to View PricesCustomers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region. -
Reference Electrode Salt Bridge Kit
AKTUBE1420 -
Fritted Isolation Tube
RRPG097Login to View PricesCustomers must be logged into their account to view prices. Not all regions provide pricing online. If you do not see prices, you can obtain them from the designated sales channel in your region.
